P0138 Technical Description
Oxygen Sensor Circuit High Voltage (Bank 1, Sensor 2)
If you’re seeing the P0138 code on your car’s OBD-II scanner, this guide is for you. We’ll cover the meaning, symptoms, causes, and fixes for this issue.
I’ve fixed this code countless times in the past.
You’ll learn why this code pops up, how it affects your vehicle, and the steps to clear it. You’ll also understand common symptoms and underlying causes.
Let’s dive right in and get your car running smoothly again.
Key Takeaways
- P0138 means the O2 sensor in Bank 1, Sensor 2 has high voltage.
- Common symptoms include the Check Engine Light, poor fuel efficiency, and rough idling.
- Causes range from a faulty O2 sensor to exhaust leaks and fuel system issues.
- Diagnose by inspecting the sensor, wiring, and exhaust for damage or faults.
- Fix by replacing damaged parts, repairing wiring, and checking the catalytic converter.
- Clearing the code and a test drive ensure the issue is resolved.
Table of ContentsShow
What Does P0138 Trouble Code Mean?
The P0138 trouble code indicates that the voltage from the oxygen sensor (O2 sensor) in Bank 1, Sensor 2 is too high.
The O2 sensor measures the amount of oxygen in the exhaust gas, which helps the engine control module (ECM) adjust the air-fuel mixture for optimal combustion.
Bank 1 refers to the side of the engine with the first cylinder, and Sensor 2 refers to the sensor located after the catalytic converter.
When the ECM detects a high voltage signal from this sensor, it means there’s an issue with the sensor itself or the exhaust gas has an unusually high oxygen content.
This can result in poor fuel economy, higher emissions, and potential damage to the catalytic converter if left unresolved.
A high voltage reading typically means the sensor is reporting a rich mixture (too much fuel and not enough air).
This could be due to various issues like a malfunctioning O2 sensor, a wiring problem, or an exhaust leak.
It’s also possible that the catalytic converter isn’t functioning correctly, affecting the sensor’s readings.
Ignoring the P0138 code can lead to more serious problems. The car’s performance may decrease, fuel consumption can increase, and you may fail an emissions test.
Additionally, running the engine with an incorrect air-fuel mixture for extended periods can damage other components.
In summary, P0138 signals that the O2 sensor after the catalytic converter is reading higher-than-normal voltage.
This is often due to a rich fuel condition or a faulty sensor, both of which need attention to maintain your vehicle’s performance and efficiency.
P0138 Trouble Code Symptoms
Here are the common symptoms you might experience with the P0138 trouble code:
- Check Engine Light is on
- Decreased fuel efficiency
- Poor engine performance
- Rough idling
- Increased exhaust emissions
- Possible catalytic converter damage
- Failed emissions test
P0138 Trouble Code Causes
These are the typical causes of the P0138 trouble code:
- Faulty O2 sensor (Bank 1, Sensor 2)
- Damaged or frayed wiring in the O2 sensor circuit
- Exhaust leaks
- Fuel injector issues causing a rich fuel mixture
- Faulty fuel pressure regulator
- Malfunctioning catalytic converter
- Short in the O2 sensor heater circuit
How To Fix A P0138 Trouble Code
Fixing a P0138 trouble code involves diagnosing the root cause and then addressing it. Here’s a step-by-step guide to help you through the process:
1. Check the O2 Sensor
Start by inspecting the O2 sensor (Bank 1, Sensor 2). Look for any visible damage or frayed wires. Replace the sensor if it appears damaged.
2. Inspect the Wiring
Check the wiring and connectors around the O2 sensor. Look for loose connections, corrosion, or broken wires. Repair or replace any damaged wiring.
3. Test the O2 Sensor
Use a multimeter to test the sensor’s voltage output. The voltage should fluctuate between 0.1V and 0.9V. If it’s consistently high, the sensor may be faulty and need replacement.
4. Check for Exhaust Leaks
Inspect the exhaust system for any leaks, especially near the O2 sensor and catalytic converter. Repair any leaks found.
5. Inspect the Fuel System
Check the fuel injectors and fuel pressure regulator. Look for signs of a rich fuel mixture, such as black smoke from the exhaust. Repair or replace faulty components.
6. Examine the Catalytic Converter
A malfunctioning catalytic converter can affect O2 sensor readings. Have the catalytic converter tested and replace it if it’s not working properly.
7. Check the O2 Sensor Heater Circuit
A short in the heater circuit can cause the P0138 code. Test the heater circuit for continuity and repair any issues found.
8. Clear the Code and Test
After performing the necessary repairs, clear the trouble code using an OBD-II scanner. Test drive the vehicle to ensure the code doesn’t return.
By following these steps, you should be able to identify and fix the cause of the P0138 trouble code, restoring your vehicle’s performance and efficiency.
Conclusion
You now know what the P0138 trouble code means and how to fix it. Ready to tackle it?
